55mm Thrust Needle Roller Bearing AXK 5578 55*78*3

100pcs
MOQ
0.1~100$/pcs
Price
55mm Thrust Needle Roller Bearing AXK 5578 55*78*3
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Roller
Structure: Thrust
Applicable Industries: Retail
Precision Rating: P6 P5 P4 P2 P0
Seals Type: OPEN / RS /ZZ
Number Of Row: Single Row / Double
Product Name: Thrust Roller Bearing AXK 5578
Material: GCR15
Feature: Long Life
MAIN MARKET: America Europe Asia Middle Africa
Application: Auto Parts
Cage: V1 V2 V3 V4
Model: AXK 5578
Size: 55*78*3
Package: Original Package
Brand: OTOTRI
Product Name: Needle Roller Bearing
Precision Grade: P5 P6
OEM/ODM: Available
Cage Material: Steel , Nylon
Clearance: C0,C2,C3,C4,C5 Is Available
Highlight:

55mm Thrust Needle Roller Bearing

,

axk 5578 bearing

,

AXK 5578

Basic Infomation
Place of Origin: Changzhou Jiangsu China
Brand Name: OTOTRI
Certification: ISO
Model Number: AXK 5578
Payment & Shipping Terms
Packaging Details: Plastic packaging + brand box + carton
Delivery Time: 5-7 days after receiving your payment
Payment Terms: L/C,T/T,Western Union,MoneyGram,Paypal
Supply Ability: 10000pcs/week
Product Description
Surface Bearing Needle Roller Single Row Plain Flat Thrust Needle Bearing AXK 5578 55*78*3 Axial Needle Roller Bearing
Product Description
55mm Thrust Needle Roller Bearing AXK 5578 55*78*3 0

Needle roller bearing

1.Bearing Specifications :
Needle roller bearings use long, thin cylindrical rollers to support radial loads. These needle rollers have a length that is
typically three to four times its diameter. Needle roller bearings have a thinner cross section than other roller bearings and are ideal for limited-space applications that require carrying heavy loads. Drawn cup needle roller bearings have a deeply drawn, thin-walled outer ring. Caged drawn cup units contain a one-piece cage to guide and retain the rollers. Full-complement drawn cup units include the maximum number of rollers that can be retained by the outer shell. The drawn design allows for cost-effective accommodation of heavy radial loads. Needle roller and cage assemblies do not contain inner or outer rings. Instead, the self-contained bearing components work with a shaft or housing bore used as a raceway.

2.Application of Bearing :
1.Needle roller bearing: used in automobile engine, transmission, crawler wheel of excavator, compressor, crane, etc.2.Combined needle roller bearing is widely used in machine tools, metallurgical machinery, textile machinery, printing machinery and other mechanical equipment, and can make the mechanical system design very compact and smart.

3.CROWNTRANS Bearing Features :
Lower cross-section height and higher load capacity than traditional ball bearings.
Small and compact for reduced overall machine size in light weighting efforts.
Widely used in automobiles, motorcycles, printing presses, industrial robots, construction equipment and other demanding
applications.
Many styles to choose from including: radial, thrust and combined models, cam followers and roller followers..
55mm Thrust Needle Roller Bearing AXK 5578 55*78*3 1
55mm Thrust Needle Roller Bearing AXK 5578 55*78*3 2
55mm Thrust Needle Roller Bearing AXK 5578 55*78*3 3
P/N
Surface Bearing Needle Roller Single Row Plain Flat Thrust Needle Bearing AXK 5578 55*78*3 Axial Needle Roller Bearing


Brand
OEM


Precision
ABEC-1


Type
Needle Roller Bearings


Lubrication
Oil


Material
Chrome Steel


Package
Plastic Bag and Box


Payment Item
T/T ,Western Union , Paypal ,Credit card


Delivery time
3-10day


55mm Thrust Needle Roller Bearing AXK 5578 55*78*3 4
55mm Thrust Needle Roller Bearing AXK 5578 55*78*3 5
55mm Thrust Needle Roller Bearing AXK 5578 55*78*3 6
Size Information
Bearing Part No.
Dc1
Dc
Dw
AXK0414-TV
4
14
2
AXK0515-TV
5
15
2
AXK0619-TV
6
19
2
AXK0821-TV
8
21
2
AXK1024
10
24
2
AXK1226
12
26
2
AXK1528
15
28
2
AXK1730
17
30
2
AXK2035
20
35
2
AXK2542
25
42
2
AXK3047
30
47
2
AXK3552
35
52
2
AXK4060
40
60
3
AXK4565
45
65
3
AXK5070
50
70
3
AXK5578
55
78
3
AXK6085
60
85
3
AXK6590
65
90
3
AXK7095
70
95
4
AXK75100
75
100
4
AXK80105
80
105
4
AXK85110
85
110
4
AXK90120
90
120
4
AXK100135
100
135
4
AXK110145
110
145
4
AXK120155
120
155
4
AXK130170
130
170
5
AXK140180
140
180
5
AXK150190
150
190
5
AXK160200
160
200
5
